About the Cat 918M Small Wheel Loader



Introducing the all new Cat 918M Small Wheel Loader. This new model to the compact loader family features the Optimized Z-bar Loader Linkgage to handle loads with precise control, all around visibility from the comfort of the heated, air suspension seat inside the cab, as well as the standard fuel savings Eco Mode. The intuitive controls and compact size of this machine make it quick and easy to operate in tight spaces. Indispensible to any jobsite, the 918M is a powerful fuel efficient machine giving you the best value in its size class.

Specifications

Engine
Net Power 113 HP
Engine Model Cat C4.4 ACERT™
Maximum Gross Power - ISO 14396 115 HP
Maximum Gross Power - ISO 14396 (DIN) 117 HP
Maximum Gross Power - Maximum Engine Speed 2350 r/min
Maximum Gross Power - SAE J1995 117 HP
Rated Net Power - Rated Engine Speed 2200 r/min
Rated Net Power - SAE J1349 112 HP
Maximum Gross Power 115 HP
Bore 4.13 in
Stroke 5 in
Displacement 268 in³
Emissions Engine meets U.S. EPA Tier 4 Final/EU Stage IV emission standards.
Maximum Gross Torque - ISO 14396 369 ft·lbf
Maximum Gross Torque - SAE J1995 372 ft·lbf
Maximum Net Torque - ISO 9249 365 ft·lbf
Maximum Net Torque - SAE J1349 361 ft·lbf
Note Net power advertised is the power available at the flywheel plus front drive implement pump when the engine is equipped with fan, air cleaner, muffler and alternator.
Rated Net Power - ISO 9249 113 HP
Rated Net Power - ISO 9249 (DIN) 114 HP
Weights
Operating Weight 20917 lb
Service Refill Capacities
Cooling System 5.7 gal (US)
Engine Crankcase 2.3 gal (US)
Fuel Tank 40.7 gal (US)
Hydraulic System - Including Tank 25.9 gal (US)
Transmission 0.9 gal (US)
Axles - Front 4.5 gal (US)
Axles - Rear 4.5 gal (US)
Diesel Exhaust Fluid (DEF) Tank 5 gal (US)
Hydraulic Tank 14.5 gal (US)
Note DEF used in Cat SCR systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241-1.
Operating Specifications
Rated Bucket Capacity 2.5 yd³
Buckets
Bucket Capacities 1.3-1.9 m3 (1.7-2.5 yd3)
Cab
ROPS SAE J1040 MAY94, ISO 3471-1994
FOPS SAE J/ISO 3449 APR98, Level II, ISO 3449 1992 Level II
Note (1) Cab and Rollover Protective Structures (ROPS) are standard in North America and Europe.
Note (2) The declared dynamic operator sound pressure levels per ISO 6396:2008*, when properly installed and maintained, is 77 dB(A).
Note (3) The labelled sound power level for the CE marked configurations when measured according to the test procedure and conditions specified in 2000/14/EC is 103 dB(A).
Note (4) *The measurements were conducted with the cab doors and windows closed.
Axles
Front Fixed; Locking differential (standard)
Rear Oscillating ±11 degrees; Locking differential (standard)
Loader Hydraulic System
Hydraulic Cycle Time - Dump, at Maximum Reach 1.8 s
Hydraulic Cycle Time - Float Down, Maximum Lift to Ground Level 2.7 s
Hydraulic Cycle Time - Rackback 2.2 s
Hydraulic Cycle Time - Raise, Ground Level to Maximum Lift 4.8 s
Hydraulic Cycle Time - Total Cycle Time 11.5 s
Maximum Flow - Implement Pump 43.6 gal/min
Maximum Flow - Implement Pump - 3rd Function, Maximum Flow, High 40 gal/min
Maximum Flow - Implement Pump - 3rd Function, Maximum Flow, Standard 25 gal/min
Maximum Flow - Implement Pump - 4rd Function, Maximum Flow 25 gal/min
Maximum Working Pressure - Implement Pump 4061 psi
Note All cycle times listed are with cylinder snubbing turned off.
Relief Pressure - Tilt Cylinder 4641 psi
Relief Pressure - Tilt Cylinder - 3rd Function Relief Pressure 4641 psi
Relief Pressure - Tilt Cylinder - 4th Function Relief Pressure 4641 psi
Steering
Maximum Flow - Steering Pump 21.7 gal/min
Maximum Working Pressure - Steering Pump 3190 psi
Number of Steering Wheel Turns - Full Left to Full Right or Full Right to Full Left 3.4 turns
Steering Articulation Angle - Each Direction 40 °
Steering Cycle Times - Full Left to Full Right - At 2,350 rpm: 90 rpm Steering Wheel Speed 2.3 s
Tires
Note (1) Other tire choices are available. Contact your Cat dealer for details.
Note (2) In certain applications, the loader's productive capabilities may exceed the tire's tonnes-km/h (ton-mph) capabilities.
Note (3) Caterpillar recommends that you consult a tire supplier to evaluate all conditions before selecting a tire model.
Other Choices Include 17.5-25 12PR L2; 17.5-R25 XHA * L3; 17.5-R25 * L2/L3 PC RM; 17.5-25 16PR L3, 3PC Rim; 17.5-25 GY L2/L3; 17.5-25 12PR L2, SNOW; Flexport™
Standard Size 17.5-25 12PR
Transmission
Forward and Reverse - High Range 25 mile/h
Forward and Reverse - Low Range, Speed Range 1* 6.3 mile/h
Forward and Reverse - Low Range, Speed Range 2 12.5 mile/h
Note *Creeper Control allows speed control from a stand still up to 10 km/h (6.3 mph). The Creeper Control will only work in Range 1.

Features

Cat® Optimized Z-bar Loader Linkage

Cat® Optimized Z-bar Loader Linkage
The Cat Optimized Z-bar Loader linkage combines the digging efficiency of a traditional Z-bar with tool carrier capabilities for great performance and versatility. You can safely and confidently handle loads with precise control with parallel lift and high tilt forces throughout the working range
918M Compact Wheel Loader

Work Tools

Work Tools
The 918M features the Cat exclusive, Performance Series Buckets, as well as high visibility pallet forks. These tools enhance productivity and are available with either an Integrated Toolcarrier (IT) or ISO (wide) coupler style. Legacy coupler tools such as brooms, grapple buckets, multi-purpose buckets and other work tools remain compatible.
918M Compact Wheel Loader

Hydraulics and Controls

Hydraulics and Controls
State of the art electro-hydraulic system provides low effort, fine control with fast cycle times. All-in-one joystick helps keep eyes on the work. Operator can adjust machine responsiveness with the push of a button, which allows the operator to set up the machine exactly the way they want it based on the application. High Flow option allows for the use of even the most demanding work tools.

Tuned Drivetrain

Tuned Drivetrain
Smooth shifting and powerful acceleration is matched with modulated hydrostatic braking in the inching/braking pedal, creating a rhythm for material moving. Creeper and electronic engine speed control makes broom and snow blower work easy. Operator tunes between smooth or aggressive shifting with the push of a button.

Cab

Cab
All around visibility is further enhanced with the availability ofa rearview camera. The deluxe cab ensures operator comfort witha heated, air suspension seat and easy to use controls. Available features such as Implement and Hystat Aggressiveness, Ride Control, Lift and Tilt Kickouts, Engine Speed Control and Rimpull Control allow the operator to customize the machine via a soft touch keypad.

Serviceability

Serviceability
Extended service intervals and excellent service access make daily checks quick and easy allowing you to get to work sooner.

Efficiently Powerfull

Efficiently Powerfull
High full turn tipping loads, powerful breakout forces and increased engine power, the M Series delivers a balanced solution for all customer applications.

Standard Fuel Savings Features

Standard Fuel Savings Features
Fuel savings features such as Eco Mode, On-Demand Cooling Fan and Auto Engine Idle Shutdown, make the 918M both powerful and fuel efficient.
