Cat PM310 Track Undercarriage

Cold planer on tracks

View brochure Request quotation
PM313 with Track Undercarriage
PM313 with Track Undercarriage

About the Cat PM310 Track Undercarriage



The new PM300 models with a track undercarriage combine enhanced production capabilities, optimized performance and simplified service to complete tough milling applications with productive results.

Specifications

Weights
Operating Weight - With Full Water Tank 47746 lb
Shipping Weight - With Empty Water Tank 44187 lb
Operating Specifications
Inside Turn Radius 6.3 ft
Maximum Travel Speed 3.4 mile/h
Operating Speed 108 ft/min
Engine
Engine Model C9.3 ACERT
Gross Power 325 HP
Dimensions
Operating Length - Conveyor Up 36.45 ft
Operating Width 8.37 ft
Maximum Operating Height 16.89 ft
Minimum Operating Height 9.84 ft
Maximum Truck Clearance 15.425 ft
Shipping Length - Base Machine 19.35 ft
Shipping Maximum Height 9.77 ft
Shipping Width 8.37 ft
Shipping Length - With Conveyor Folded 30.58 ft
Rotor Assembly
Cutting Width 39.4 in
Maximum Cutting Depth 13 in
Number of Cutting Tools 97
Conveyor System
Collecting Conveyor Speed 827 ft/min
Collecting Conveyor Width 21.6 in
Discharge Conveyor Length 23.6 ft
Discharge Conveyor Width 23.6 in
Discharge Conveyor Maximum Speed 827 ft/min
Discharge Conveyor Swing - From Center 60 °
Service Refill Capacities
Fuel Tank Capacity 158.5 gal (US)
Water Spray System 333 gal (US)

Features

Features

Simple Operation

LCD Touchscreen Displays
LCD touchscreen displays are clear and provide fingertip access to multiple levels of information
Backlit Buttons
Backlit buttons are easy to see and use
Automated Functions
Automated functions simplify starts and consistency
Cat Grade Control
Optional Cat Grade Control is integrated with the machine, easy to use and precise

Comfortable Operator's Station

Ergonomic Operator's Console
Ergonomic operator's console is comfortably arranged and easy to use
Power Canopy
Optional power canopy provides greater operator comfort
Adjustable Seat
Seat is adjustable and comfortable
Dust Abatement
Optional Dust Abatement System removes dust from work enviroment; system can be enhanced with optional additional water spray system
Lockable Storage Bin
Large lockable storage bin is convenient and useful

Versatile and Productive

Electronically Controlled Rear Steering
Enhances maneuverability, facilitating operation in confined areas
Heavy Duty Powertrain
Powerful Cat 9.3 ACERT engine delivers reliable, ample power to the propel system and rotor drive system
Automatic Load Control
Automatic Load Control provides optimum cutting performance even in deep plunge cuts
Three Cutting Speeds
Three cutting speeds can be electronically selected and provide optimal performance to match the application need
Automatic Belt Tensioning
Rotor drive belts are automatically tensioned to ensure steady power to rotor and prevent slippage
Articulating Rear Right Lifting Column
Articulating right rear lifting column can be positioned outboard for maximum stability or inboard to enhance flush cutting capability
Traction Control
Traction control system reduces slippage
Cat Diamond Bits
Optional Cat Diamond Bits last up to 80 times longer than standard carbide bits; reduce wear on machine and fuel consumption
Loading Conveyor
Loading conveyor swings 60 degrees to right or left of center to maximize loading flexibility; folds for transport

Easy Service

Large Service Doors
Large doors provide access to critical service areas
Visual Indicators
Visual indicators provide status at a glance
Electronic Control Modules (ECMs)
Electronic Control Modules (ECMs) monitor machine function, providing alerts and diagnosis
Long Service Intervals
Long service intervals reduce costs and maximize uptime
Accessory Drive System
Optional Accessory Drive System provides full operational control of main machine functions for assisted machine movement during maintenance and service
Convenient Parts Availability and Dealer Support
Fast delivery of parts and industry-leading dealer service and support helps keep your machine investment working and productive
